Introduction

Create order after user scan the QRcode.

API Description

Request Method:POST

Request Path:open/api/scan/payment

Parameters

Request Parameters

Parameter	Sign	Mandatory	Type	Length	Description
appId	Y	Y	string	64	AppId is unique for merchant
sign	N	Y	string	256	Sign
merchantOrderNo	Y	Y	string	64	Merchant order number (must be unique)
qrCode	Y	Y	string	256	QR Code string
amount	Y	Y	string	20	Order amount
currency	Y	Y	string	20	Fiat currency (unit of amount)
userId	Y	Y	string	64	UserId is unique for user (email / phone number)
userIp	Y	Y	string	32	User IP address
callbackUrl	Y	Y	string	128	The address receiving order webhook
customParam	N	N	string	1024	Custom fields
└expireTime	N	N	int		Expire time in second
└returnUrl	N	N	string		The redirection address after the successful purchase
└cancelUrl	N	N	string		The redirection address after the order cancel
└goods	N	N	object		Goods information
└─goodsId	N	N	object		Goods ID
└─goodsName	N	N	int		Goods name
└─goodsDesc	N	N	string		Goods description

Example

{
    "appId": "TEST000001",
    "sign": "TEST000001",
    "merchantOrderNo": "11126",
    "amount": "100000",
    "currency": "VND",
    "feeType","INNER_BUCKLE",
    "qrCode": "00020101021138580010A000000727012800069704070114190360421800120208QRIBFTTA53037045802VN830084006304EDC5",
    "userId": "505*****78@qq.com",
    "userIp": "127.0.0.1",
    "callbackUrl": "http://127.0.0.1:8022/open/api/callback",
    "customParam": {
        "expireTime": 360000,
        "returnUrl": "http://www.kucoinpay.com/order/success",
        "cancelUrl": "http://www.kucoinpay.com/order/cancel",
        "goods": [
            {
                "goodsId": "1",
                "goodsName": "Gift card",
                "goodsDesc": "Gift card product"
            }
        ]
    }
}

Response Parameters

Parameter	Type	Description
success	boolean	Success
error	boolean	Error
code	long	Response code
msg	string	Response message
traceId	string	Trace id
model	object	Response content

Model Response Parameters

Parameter	Type	Description
requestId	string	The unique Merchant Trade No generated by merchants
payOrderId	string	KuCoin Pay unique order ID
expireTime	string	Order expiration time
qrcode	string	QR code image link
appPayUrl	string	Checkout page URL hosted by KuCoin Pay

Example

{
  "code": "0",
  "msg": "success",
  "model":{
       "requestId": "0a5f77dd-5679-48d1-8872-2fb9a35cc969",
       "payOrderId": "kpt_2024120306484849000911110112",
       "expireTime": 1733210327961,
       "qrcode": "https://nginx-web-01.sit.kucoin.net/pay/checkout/kpt_2024120306484849000911110112",
       "appPayUrl": "https://nginx-web-01.sit.kucoin.net/pay/checkout/kpt_2024120306484849000911110112"
},
  "traceId": "6668024eeb989c77a375967aded5d646",
  "success": true,
  "error": false
}
